SkyAir Non Inverter R-32 – Tipe Duct Connection Middle Static Pressure.

Spesifikasi	2 PK	2.5 PK	3.5 PK	3.5 PK	4 PK	5 PK	6 PK
Model Set	SDMC50AVR/L	SDMC60AVR/L	SDMC85AVR/L	SDMC85AYR/L	SDMC100AYR/L	SDMC125AYR/L	SDMC140AYR/L
Kapasitas	2 PK 18,500 Btu/h 5.42 kW	2.5 PK 23,500 Btu/h 6.89 kW	3.5 PK 30,000 Btu/h 8.79 kW	3.5 PK 29,500 Btu/h 8.65 kW	4 PK 36,000 Btu/h 10.55 kW	5 PK 42,000 Btu/h 12.31 kW	6 PK 48,000 Btu/h 14.07 kW
Daya Listrik	1,750 W	2,290 W	2,770 W	2,720 W	3,250 W	3,660 W	4,100 W
COP	3.10	3.01	3.17	3.18	3.25	3.36	3.43
Refrigeran	R-32	R-32	R-32	R-32	R-32	R-32	R-32
Power Supply	220–240V, 1Ø, 50Hz	220–240V, 1Ø, 50Hz	220–240V, 1Ø, 50Hz	220–240V, 1Ø, 50Hz	380–415V, 3Ø, 50Hz	380–415V, 3Ø, 50Hz	380–415V, 3Ø, 50Hz
Harga Wired	Rp 13.840.000	Rp 18.130.000	Rp 20.900.000	Rp 22.550.000	Rp 23.980.000	Rp 29.930.000	Rp 34.130.000
Harga Wireless	Rp 14.010.000	Rp 18.300.000	Rp 21.070.000	Rp 22.720.000	Rp 24.150.000	Rp 30.100.000	Rp 34.300.000

Spesifikasi	2 PK	2.5 PK	3.5 PK	3.5 PK	4 PK	5 PK	6 PK
Model Indoor	FDMC50AV14	FDMC60AV14	FDMC85AV14	FDMC85AV14	FDMC100AV14	FDMC125AV14	FDMC140AV14
Dimensi (HxWxD)	250 × 700 × 700 mm	250 × 700 × 700 mm	250 × 1.000 × 700 mm	250 × 1.000 × 700 mm	250 × 1.400 × 700 mm	250 × 1.400 × 700 mm	250 × 1.400 × 700 mm
Berat Mesin	24 kg	24 kg	31 kg	31 kg	40 kg	40 kg	42 kg

Spesifikasi	2 PK	2.5 PK	3.5 PK	3.5 PK	4 PK	5 PK	6 PK
Model Outdoor	RC50AV14	RC60AV14	RC85AV14	RC85AY14	RC100AY14	RC125AY14	RC140AY14
Dimensi (HxWxD)	615 × 845 × 300 mm	615 × 845 × 300 mm	695 × 930 × 350 mm	695 × 930 × 350 mm	852 × 1.030 × 400 mm	852 × 1.030 × 400 mm	852 × 1.030 × 400 mm
Berat Mesin	40 kg	46 kg	56 kg	57 kg	64 kg	79 kg	84 kg
Ukuran Pipa Cair	1/4 inch	1/4 inch	3/8 inch	3/8 inch	3/8 inch	3/8 inch	3/8 inch
Ukuran Pipa Gas	1/2 inch	1/2 inch	5/8 inch	5/8 inch	5/8 inch	5/8 inch	5/8 inch
Maksimal Pipa — Panjang	35 m	35 m	50 m	50 m	50 m	50 m	50 m
Maksimal Pipa — Tinggi	20 m	20 m	30 m	30 m	30 m	30 m	30 m

Pilihan Kapasitas
